Technical Specifications Hardware CPU AMD Ryzen™ V1780B quad-core (8-thread) 3.35 GHz, max boost clock up to 3.6 GHz Hardware encryption AES-NI Memory 8 GB DDR4 ECC UDIMM (expandable up to 32 GB) Compatible drive types • 12 x 2.5" SATA SSD (drives not included) • Only drives listed on the compatibility list can be used to create storage pools6 Hot swappable drives Yes External ports 2 x USB 3.2 Gen 1 ports Form factor Rackmount 1U Size (HxWxD) • 44 x 437.5 x 521.9 mm • 44 x 481.9 x 555.9 mm (with server ears) Weight 8.3 kg LAN ports • 2 x 1GbE RJ-45 • 2 x 10GbE RJ-45 Wake on LAN/WAN Yes (only on 1GbE ports) PCIe expansion • 1 x 8 width slot, Gen 3.0 x4 lanes • Supports network interface cards3 Scheduled power on/off Yes System fans 4 x (40 x 40 x 28 mm) AC input power voltage 100 V to 240 V AC Power frequency 50/60 Hz, single phase Operating temperature 0°C to 35°C (32°F to 95°F) Storage temperature -20°C to 60°C (-5°F to 140°F) Relative humidity 5% to 95% RH Maximum operating altitude 5,000 m (16,400 ft)
General DSM Specifications Networking protocols SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN™, L2TP) File systems • Internal: Btrfs, ext4 • External: Btrfs, ext4, ext3, FAT32, NTFS, HFS+, exFAT Supported RAID types Synology RAID F1, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10 Storage management • Maximum single volume size: 108 TB/200 TB7 • Maximum number of system snapshots: 65,5368 • Maximum number of internal volumes: 256
Package contents • 1 x FS2500 main unit • 1 x Quick Installation Guide • 1 x Accessory pack • 2 x AC power cord
